ANSI B18.2.4.5m Heavy Hex Jam Nut Carbon Steel Gr4 / Gr8 For Widest Application

ANSI B18.2.4.5m Heavy Hex Jam Nut Carbon Steel Gr4 / Gr8 For Widest Application

    • ANSI B18.2.4.5m Heavy Hex Jam Nut  Carbon Steel Gr4 / Gr8 For Widest Application
    • ANSI B18.2.4.5m Heavy Hex Jam Nut  Carbon Steel Gr4 / Gr8 For Widest Application
    • ANSI B18.2.4.5m Heavy Hex Jam Nut  Carbon Steel Gr4 / Gr8 For Widest Application
    • ANSI B18.2.4.5m Heavy Hex Jam Nut  Carbon Steel Gr4 / Gr8 For Widest Application
  • ANSI B18.2.4.5m Heavy Hex Jam Nut  Carbon Steel Gr4 / Gr8 For Widest Application

    Detail produk:

    Place of Origin: CN
    Nama merek: HNF
    Sertifikasi: ISO9001:2008
    Model Number: M5-M36

    Syarat-syarat pembayaran & pengiriman:

    Minimum Order Quantity: 1000 piece
    Harga: Negotiation
    Packaging Details: Common export packing. Cartons+Pallets, or customized packing. Bag Packing
    Delivery Time: 10-20 days
    Payment Terms: L/C, T/T, Western Union, Paypal
    Supply Ability: 500 tons per month
    Hubungi sekarang
    Detil Deskripsi produk
    Product: Hex Head Nut Head Drive: Hexagonal
    Standard: DIN ANSI JIS Bsw Surface: Plain Finish
    Material: Stainless steel Head: Hex Head
    HS Code: 731816 Inspection: 100%QC Steps Inspect Before Shipment
    Connection: Common nut



    Carbon Steel Gr4 Gr8 DIN936 ANSI B18.2.4.5m Hex Jam Nuts M5-M36 Hex Head Jam Nut

    Description:


    Hexagon Head Nut play the role of a component of all manufacturing machinery. It fastener other components. There are kinds of nut. We have common national standard, German standard, the British standard, American Standard, the subject of the nut. There are many kinds of lock nut. Hex Head Nut is very common.

    Hex nut, according to the nominal thickness, is divided into type I, type II and thin nut. Hex Jam Nut. Above Grade 8 nuts , which is divided into Type 1 and Type II two types.

    I type hexagon nuts widest application, a nut is divided into A, B, C three, where A and B grade nuts applied to the surface roughness is small, the high requirements for precision machinery, equipment and structures, and C grade nuts are used for relatively rough surface of the machinery, equipment or structures less precision; type 2 hex nut relatively thick, more often need to be used in assembly and disassembly of the occasion.

    Type 1 nut refers nominal nut height m≥0.8D ordinary hex nut, of the type size should be consistent with the provisions of GB / T6170's;

    The height of type 2 than type 1 nut to nut, of the type size should be consistent with GB / T6175. Increase in type 2 nuts two purposes: First, to obtain a nut without heat treatment by increasing the height, relatively low nut.

    The hex jam nuts are cutted from common hex nuts. Cost is higher.



    Specification:



    ANSI B18.2.4.5m Heavy Hex Jam Nut  Carbon Steel Gr4 / Gr8 For Widest Application



    Item Carbon Steel Gr4 Gr8 DIN936 ANSI B18.2.4.5m Hex Jam Nuts M5-M36 Hex Head Jam Nut
    size M5-M36
    Material Available Carbon Steel
    Surface treatment Electro plating, Black, Plain
    Heat treatment Tempering, Hardening, Spheroidizing
    Tolerance 6g
    Packing Plastic bags + carton box + pallet
    Lead time About 15-25 days. Reality time is according to customer's requirement
    Origin of Country China



    Material Proof strength Min. tensile yield strength Min. tensile ultimate strength Nut class
    ISO898
    Low or medium carbon steel 380 MPa (55ksi) 420 MPa (61 ksi) 520 MPa (75 ksi) 5
    Medium carbon steel Q&T 580 MPa (84 ksi) 640 MPa (93 ksi) 800 MPa (116 ksi) 8
    Alloy steel Q&T 830 MPa (120 ksi) 940 MPa (136 ksi) 1040 MPa (151 ksi) 10
    SAE J995
    Low or medium carbon steel 55 ksi (379 MPa) 57 ksi (393 MPa) 74 ksi (510 MPa) 2
    Medium carbon steel Q&T 85 ksi (586 MPa) 92 ksi (634 MPa) 120 ksi (827 MPa) 5
    Alloy steel Q&T 120 ksi (827 MPa) 130 ksi (896 MPa) 150 ksi (1034 MPa) 8



    Application:

    Hex Jam Nut is same as Hex Head Nut, which is most common in usage, which is mainly used for fastener one thing by the nuts. And it has requirement of the torque, and we will control the torque for customers.



    Advantages:


    1. Over 6 years of manufactiring experience
    2. Many kinds of stock
    3. Competitive price
    4. Quality control system

    5. Sample available

    6. The fastest response
    7.
    The best service



    ANSI B18.2.4.5m Heavy Hex Jam Nut  Carbon Steel Gr4 / Gr8 For Widest Application
